Circular vibrating screen
- Product Category:Vibration Screening Machine Series
- Popular tags:Circular vibrating screen quotation, vibrating screen brand
Parameter table of circular vibrating screen | |||||||||
model | HYVL-400 | HYVL-600 | HYVL-800 | HYVL-1000 | HYVL-1200 | HYVL-1500 | HYVL-1800 | HYVL-2000 | |
Effective screening diameter | Φ340 | Φ340 | Φ730 | Φ900 | Φ1100 | Φ1400 | Φ1700 | Φ1886 | |
Effective screening area | 0.0907 | 0.2289 | 0.4183 | 0.6359 | 0.9499 | 1.5386 | 2.2687 | 2.7922 | |
Screen specifications | 2-500目/时meshes/inch | ||||||||
Layer by | 1/5 | 1/5 | 1/5 | 1/5 | 1/5 | 1/5 | 1/3 | 1/3 | |
Power | Vibrator Motor | 0.18 | 0.25 | 0.55 | 1.1 | 1.1 | 1.5 | 2.2 | 2.2 |
Ordinary Motor | 0.75 | 1.1 | 1.5 | 1.1 | 2.2 | 3.0 | 3.0 |
Characteristics of circular vibrating screen
1. High efficiency, exquisite and durable design, can sieve any powder or mucus; Easy to change the network, simple to operate, and easy to clean;
2. The mesh is not blocked, the powder does not fly, and it can be sieved up to 325 mesh or 0.028mm; Impurities and coarse materials are automatically discharged and can be operated continuously; Unique grid design, long-lasting use of mesh, fast replacement of mesh
3. It only takes 3-5 minutes; Small size, space saving, easy to move; The screening machine can reach up to five layers, and it is recommended to use three layers.
Industry of use
Chemical industry: resins, industrial drugs, cosmetics, paints, traditional Chinese medicine powders, etc;
Food industry: sugar powder, starch, salt, Rice noodles, milk powder, soybean milk, egg powder, soy sauce, fruit juice, etc;
Metal and metallurgical industries: aluminum powder, lead powder, copper powder, ore, alloy powder, welding rod powder, manganese dioxide, point decomposed copper powder, point magnetic materials, grinding powder, refractory materials, aged soil, lime, alumina, heavy calcium carbonate, quartz sand, etc;
Other industries: oil consumption, wastewater, dyeing and finishing wastewater, papermaking, additives, activated carbon, etc.
